2024 Pivot Trail 429 Pro XT/XTR Enduro 29"

$7,699.99
Available in store: Check availability

Available in store

Close
29" Wheels | 120mm Rear/140 Front Travel | 66-66.5° HT
Add to cart
Delivery time: 5-7 Business Days
Frame Trail 429
Wheel Size 29"
Travel 120mm Rear/140 Front
Fork Fox Factory 36 29", GRIP2 - 140mm
Rear Shock Fox Factory Float DPX2
Headset Pivot Precision Sealed Cartridge
Bottom Bracket
Shifter Shimano XT M8100 ISPEC EV 12-Speed
Rear Derailleur Shimano XTR M9100 SGS 12-Speed
Cassette Shimano XT M8100 10-51t
Chain Sram X01 Eagle 12-Speed
Chainring 32t
Crankset Race Face Æffect R
Brakes Shimano XT M8120 4-piston
Rotors F: Shimano XT Centerlock 180mm | R: Shimano XT Centerlock 180mm
Seatpost Fox Transfer Factory Series 100mm (XS), 125mm (SM), 150mm (MD) 175mm (LG) 200mm (XL)
Handlebar Phoenix Team Low Rise Carbon - 780mm
Stem Phoenix Team Enduro/Trail
Grips Phoenix Factory Lock-On
Saddle Phoenix WTB Volt Pro (Medium Width)
Pedals N/A
Front Wheel DT Swiss XM1700 w/ DT Swiss 350 hub & 36t Star Ratchet 30mm - 29" 15x110
Rear Wheel DT Swiss XM1700 w/ DT Swiss 350 hub & 36t Star Ratchet 30mm - 29" 12x157 R
Front Tire Maxxis Dissector 29" x 2.4" WT, TR, 3C, EXO, MAXXTERRA
Rear Tire Maxxis Dissector 29" x 2.4" WT, TR, 3C, EXO, MAXXTERRA
Sizes XS, S, M, L, XL
FROM THE MANUFACTURER



All-Mountain Attitude, Race Bike Reflexes
The Trail 429 might well be the perfect category defying trail bike. Progressive geometry and super capable suspension give hard charging riders the tools they need to thrive in jumpy and steep terrain. 120mm of travel has never felt this plush or this composed. This very same super-refined dw-link suspension also delivers whip-crack pedal response and acceleration, aided and abetted by the strongest, lightest carbon fiber chassis we’ve ever developed. The sharp-end of the stick XC capability of this bike is eye-opening, on par with dedicated flyweight race bikes. This is a bike that you can shred with confidence everywhere from 24-hour race courses to untamed high alpine singletrack.

Evolution Of A Classic
This latest iteration of the Trail 429 is a distillation of our constant quest for peak performance; we’ve broadened its capabilities without sacrificing its legendary sharpness. In order to achieve this, we slackened the head angle just enough, increased the reach, and introduced a flip-chip to allow fine tuning of the geometry toward either the rowdy or racy ends of the spectrum. These changes all enhance stability at speed while retaining excellent pedal hammering ergonomics. Through continued evolution of our proprietary Hollow Core carbon frame construction, we carved more than 300 grams from the chassis, achieving an XC-race frame weight with incredible all-mountain strength and stiffness.

All-Star Suspension
In order to wring every drop of potential out of 120mm, we’ve reworked the already stellar dw-link suspension. A metric, trunnion mount shock and a more progressive linkage enables improved pedaling efficiency and more capability in big hits. The design provides a more bottomless feel and allows for a greater range of tunability. The Trail 429 combines rocketship pedaling performance with a plushness that genuinely feels like more travel than the numbers indicate. Is it possible for a bike to be both razor sharp and butter smooth? Yes. The Trail 429 is proof.



FEATURES



  • Refined geometry exemplifies the pinnacle of modern race-to-trail performance
  • New, more progressive dw-link® prioritizes pedaling efficiency yet still rewards with plush, controlled travel
  • 120mm rear suspension travel featuring a vertically trunnion mounted high-volume air shock delivers unprecedented comfort and tunability
  • Flip chip adjustability allows riders to tailor geometry for either all-around handling or a more progressive and rowdy demeanor
  • Hassle-free, full-length, internal cable routing with Pivot's easy to service and ultra-quiet Pivot Cable Port System
  • Fits riders between 4'10" and 6'7" with X-Small to X-Large offerings
  • Pivot's full carbon frame features size-specific ride tuning, leading edge carbon fiber materials and Pivot's proprietary hollow core molding technology to ensure that every rider from 4'11" to 6'7" has a bike that feels perfect and performs at the optimum level for their size
  • Pivot Tool Dock system compatible with mounts under the top tube and integrated into the underside of the frame



GEOMETRY & SIZING



  Low BB XS SM MD LG XL
A Seat Tube Length 34.3 cm 36.8 cm 39.4 cm 43.2 cm 47.0 cm
B Top Tube Length 57.2 cm 59.5 cm 62.8 cm 64.4 cm 66.7 cm
C Head Tube Length 8.5 cm 9.5 cm 10.7 cm 11.2 cm 12.5 cm
D Head Tube Angle 66.5°
E Seat Tube Angle 75.5°
F Chainstay Length 43.0 cm
G Bottom Bracket Height 34.7 cm
H Bottom Bracket Drop 2.7 cm
I Standover 63.6 cm 66.8 cm 67.0 cm 68.2 cm 69.6 cm
  Wheelbase 112.8 cm 115.2 cm 118.7 cm 120.4 cm 122.9 cm
  Stack 58.4 cm 59.3 cm 60.4 cm 60.9 cm 62.1 cm
  Reach 41.0 cm 43.0 cm 46.0 cm 47.5 cm 49.5 cm

  Lower BB XS SM MD LG XL
A Seat Tube Length 34.3 cm 36.8 cm 39.4 cm 43.2 cm 47.0 cm
B Top Tube Length 57.3 cm 59.6 cm 62.9 cm 64.5 cm 66.9 cm
C Head Tube Length 8.5 cm 9.5 cm 10.7 cm 11.2 cm 12.5 cm
D Head Tube Angle 66°
E Seat Tube Angle 75°
F Chainstay Length 43.2 cm
G Bottom Bracket Height 34.0 cm
H Bottom Bracket Drop 3.3 cm
I Standover 63.1 cm 66.2 cm 66.4 cm 67.7 cm 69.0 cm
  Wheelbase 112.9 cm 115.3 cm 118.8 cm 120.5 cm 123.0 cm
  Stack 58.8 cm 59.7 cm 60.8 cm 61.3 cm 62.5 cm
  Reach 40.5 cm 42.5 cm 45.5 cm 47.0 cm 49.0 cm
