120mm Front / 120mm Rear | 250Wh | Mahle X30 | 71° HT
F-PLAY. Ebikes that help you grow.
If you want your little-ones to get better at mountain biking you’ll need a bike that helps them do just that. That’s why we’ve completely redesigned our F-Play range, making them unarguably the best two-wheeled investment ever when it comes to smiles per mile. We’ve gone all-in, leveraging adult-bike tech to design the best kids bikes out there.
Suspension travel has been augmented on both models, going from 100mm on the 24” bike up to 120mm, and from 120mm to 130mm on the 26” version. The forks have also been upgraded, now 120mm on the 24” bike (up from 100mm on the old F-Play 24”) and 140mm on the 26” bike (up from 120mm on last year’s F-Play 26”).
• Improved initial sensitivity and trail compliance.
• A more progressive kinematic.
• A lighter system with improved weight to stiffness ratio.
• More compact with less unsprung weight.
• Greater seatpost insertion depth.
For-real mountain biking.
The new F-Play range blurs the line between a kids’ bike and a bike for adults. As with the rest of the KIDS ranges, the F-Play comes with 2.4” tyres, an ONOFF Pija dropper post, a 30mm stem complimentary to Forward Geometry and a 1x chainset with a UDH mech hanger. It’s by far the closest thing to an adults’ ebike available in our kids ranges. It uses the same tech, the same technical resources and even the same components so that your little-ones can feel what you feel when out on their bikes.
| Frame size | F-Play 24 | |
| A | Seattube length | 320 mm |
| B | Toptube length | 525 mm |
| C | Bottom bracket drop | -10 mm |
| D | Bottom bracket height | 295 mm |
| E | Chainstay length | 420 mm |
| F | Seat tube angle | 71º |
| G | Effective seattube angle | 76º |
| H | Headtube angle | 67º |
| I | Fork Offset | 39 mm |
| J | Wheelbase | 1050 mm |
| K | Headtube length | 90 mm |
| L | Reach | 375 mm |
| M | Stack | 513 mm |
| Frame | F-Play 24 6061 Alloy Stealth evo, hydroformed tubing, Zero Suspension System, 120mm travel, one piece bolt-on upper link, integrated internal non-removable battery, Tapered head tube, HHG internal cable routing, BSA bottom bracket, 1x drivetrain compatibl |
|---|---|
| Wheel Size | 24" |
| Travel | 120mm front / 120mm rear |
| Fork | X-Fusion Slant RC 26, 120mm, air spring, tapered steerer tube, 15x100mm axle, 34mm aluminum stanchions, 41mm offset. Settings: lockout, rebound, air preload |
| Rear Shock | X-Fusion 02PRO R, 165x42.5mm. Settings: low-speed rebound, air preload. Trunnion top, 50x8mm bottom bushings |
| Headset | Onoff ZS44/ZS56, 1-1/8", 1.5" head tube, ACB sealed bearings, top 42x30x7x45ºx45º, bottom 52x40x8x45ºx45º |
| Shifter | Shimano Deore M6100, Rapid Fire Plus, 12s |
| Rear Derailleur | Shimano Deore M6100, SGS, Shadow+, 12s |
| Cassette | Sunrace CSMZ600, 11-51T |
| Chain | Shimano Deore M6100, 12s, Quick-link |
| Chainring | 30T, steel |
| Crankset | Prowheel DMJ-CR094S-TT, Direct mount chainring, 150mm |
| Brakes | Shimano MT501, RT56 180mm IS 6 bolts rotor, resin pads |
| Rotors | RT56 180mm IS 6 bolts rotor |
| Seatpost | X-Fusion Manic LC internal, diameter 31.6mm, 1X Remote lever, 100mm |
| Handlebar | MDK XC 1.0, 6061 alloy, rise: 25mm, width: 680mm, 9º backsweep, 5º upsweep, 31.8mm barbore |
| Stem | Onoff S3 30mm 0º, 6061 forged alloy, 31.8mm barbore |
| Grips | Onoff Beehive, 1lock-on, 135mm |
| Saddle | SDG Fly JR |
| Pedals | SDG Slater JR |
| Front Wheel | MDK-HP1 24 TLR, 25mm internal width, tubeless ready, 32 spokes; DA210FS02, 15x100mm, cup & cone ball bearings, IS 6 bolts |
| Rear Wheel | MDK-HP1 24 TLR, 25mm internal width, tubeless ready, 32 spokes; Mahle-Ebikemotion X-30, HG freehub |
| Front Tire | Maxxis Minion DHF 24x2.4, Tubeless ready, 3C MAXX TERRA, EXO Protection, 60TPI, folding bead |
| Rear Tire | Maxxis Minion DHR II 24x2.3, Tubeless ready, EXO Protection, 60TPI, folding bead |
| Drive Unit | Mahle X-30 |
| Battery | Mahle IX250Wh |
| Display | iWoc ONE Head Unit |
| Extras | N/A |
| Sizes |
