Norco

Norco Charger A1 27.5"

$1,549.00

In store: Check availability

SKU: 0691015754

130mm Front | 65° HT | 27.5"

Color:

Size:

Add to compare Add to wishlist

Delivery time: 5-7 Business Days | *Bicycle shipping calculated at checkout.

Description

From the manufacturer

A hard-charging hardtail for pushing riding progression.

A low standover top tube design, modern trail geometry, and short stays make this a solid bike for anyone when heading out on your favourite trails.

Take it to the next level.

Climb mountains, ride trails, but most of all, just get out there and go further. Charger has returned as an updated staple in the Norco lineup. A hardtail that packs a lot of punch, it’s a great option for anyone pushing boundaries off the pavement and into the dirt.

A sturdy ride you can trust.

A forged bottom bracket yoke adds strength, more tire clearance, and stiffness. A tapered head tube for an integrated headset improves handling and stability.

A smooth, refined look.

Custom hydroformed aluminum frame tubing with smooth welding adds a sleek look.

Supportive, progressive design for uncompromised performance.

A low standover top tube design, modern trail geometry with a 65-degree headtube angle, and short 435 stays make this bike a solid choice for anyone when heading out on your favourite trails.

Premium frame features.

Thruaxle dropouts front and rear, and internal cable routing through the frame protects from wear and adds to the clean look and feel.

Features

Geometry

	27.5"
Travel (mm front)	130
Reach	420
Stack	617
Head Tube Angle	65°
Fork Offset	42
Seat Tube Length	370
Effective Seat Tube Angle	75°
Rear Centre Length	425
Bottom Bracket Drop	34
Bottom Bracket Height	324
Horizontal Top Tube	585
Wheelbase	1162
Standover	616
Head Tube Length	140
Trail	121
Recommended Seatpost Drop	130
Maximum Post Insertion	265
Stem Length	40
Crank Length	170
Tire Size	2.2" - 2.4"
Water Bottle Compatible	1 x 620 mL

Specifications

Frame	Aluminum, Smooth Welding, 12x148mm Boost, Tapered HT, UDH Hanger
Wheel Size	27.5"
Travel	130mm Front
Fork	Rockshox Judy S TK Air, 130mm, 51mm offset, 15x110mm Boost
Rear Shock	N/A
Headset	Sealed Cartridge Bearings, Tapered 1-1/8" - 1.5" ( IS42/28.6 \| IS52/40 )
Bottom Bracket	Shimano BB-MT501, BSA 68/73mm
Shifter	Shimano Deore SL-M6100-R, 12sp
Rear Derailleur	Shimano Deore RD-M6100, 12sp, SGS
Cassette	Shimano Deore CS-M6100, 10-51T, 12sp
Chain	KMC 12spd
Chainring
Crankset	Shimano Deore FC-MT512 2 pc, 30T, 170mm (S-M), 175mm (L - XXL)
Brakes	Shimano Deore BD-MT410, Resin pads
Rotors	Front: Shimano RT-26, 180mm, c-lock / Rear: Shimano RT-26, 160mm, c-lock
Seatpost	X-Fusion Manic LC, 31.6mm, 130mm (S), 150mm (M), 170mm (L/XL/XXL)
Handlebar	Norco Aluminum, 780mm, 30mm Rise
Stem	Alloy 40mm Length, 31.8mm Clamp
Grips	DDK lock-On, 139mm length
Saddle	WTB Volt Sport, Med
Pedals	N/A
Front Wheel	WTB ST TCS 2.0, 27mm ID, 32H; Formula DC-511, 15x110mm, 32h, C-lock
Rear Wheel	WTB ST TCS 2.0, 27mm ID, 32H; Formula DC-3248,12x148mm Boost, HG, 32h, C-lock
Front Tire	Maxxis Forekaster, 29x2.4" (27.5X2.25"size S), Wire
Rear Tire	Maxxis Forekaster, 29x2.4" (27.5X2.25"size S), Wire
Sizes	S
