A bike like Mom's or Dad's
At first sight it might be hard to tell if the F-Trick is a kids bike or a bike for adults. The design language is straight out of the NEAT or F-PODIUM handbook, with minimalistic tubes and straight lines that soften the aesthetic to give the bike a true Mondraker personality, only in small form format. The icing on top is the same new Forward Geometry as on the adult bikes but tweaked to suit kids’ needs, and details like 30mm stems to keep the steering sharp but stable.
Suspension |
Updated zero with more travel than ever before
|
|
Unlimited Fun |
Unlimited Confidence and Fun
|
Seat Tube Length | 320 |
Top Tube Length | 510 |
BB Drop | -10 |
BB Height | 280 |
Chainstay Length | 420 |
Seat Tube Angle | 71° |
Eff. Seat Tube Angle | 76° |
Headtube Angle | 66° |
Fork Offset | 41 |
Wheelbase | 964 |
Headtube Length | 90 |
Reach | 340 |
Stack | 493 |
Frame | F-Trick 24 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspension System, 120mm travel, one piece bolt-on upper link, 12x148mm rear axle, 73mm BSA bottom bracket, HHG internal cable routing, dedicated 1x drivetrain design. 26” wheelset compatible |
---|---|
Wheel Size | 24" |
Travel | 120mm Front | 120mm Rear |
Fork | X-Fusion Velvet RL 26, 120mm, air spring, tapered steerer tube, 15x100mm axle, 32mm aluminum stanchions, 41mm offset. Settings: lockout, rebound, air preload |
Rear Shock | X-Fusion 02PRO R, 165x42.5mm. Settings: low-speed rebound, air preload. Trunnion top, 50x8mm bottom bushings |
Headset | Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º |
Bottom Bracket | Sram DUB BSA, sealed bearings, 73mm |
Shifter | Sram Trigger SX Eagle, 12s, X-Actuation 1:1 |
Rear Derailleur | Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1 |
Cassette | Sram PG-1230, 11-50T, 12s |
Chain | Sram SX Eagle, 12s, Powerlock |
Chainring | |
Crankset | Sram SX Eagle, DUB axle, Direct mount chain ring, 155mm |
Brakes | Sram Level, 2 piece caliper |
Rotors | Centerline 180mm Front | Centerline 160mm Rear |
Seatpost | Onoff Pija dropper internal, diameter 31.6x100mm |
Handlebar | MDK XC 1.0, 6061 alloy, rise: 25mm, width: 680mm, 9º backsweep, 5º upsweep, 31.8mm barbore |
Stem | Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore |
Grips | Onoff Twin, 1lock-on |
Saddle | SDG Fly JR |
Pedals | N/A |
Front Wheel | MDK-XP1 24 TLR, 25mm internal width, tubeless ready, 32 spokes |
Rear Wheel | MDK-XP1 24 TLR, 25mm internal width, tubeless ready, 32 spokes |
Front Tire | Kenda Regolith 24x2.4 120TPI, folding TLR |
Rear Tire | Kenda Regolith 24x2.4 120TPI, folding TLR |
Sizes |
