2023 Yeti 160E T1 29"

$12,999.99
Available in store: Check availability

Available in store

Close
Shimano EP8 | 630Wh Battery | 160mmRear/170 Front Travel | 64.5° HT
Add to cart
Delivery time: 5-7 Business Days
Frame T1, TURQ series carbon, Shimano XT, Fox Factory GRIP 2 38 Fork
Wheel Size
Travel 160mm Rear/ 170 Front
Fork FOX FACTORY 38 GRIP 2/170MM E-Tune
Rear Shock FOX FACTORY FLOAT X2
Headset CANE CREEK 110 INTEGRATED
Shifter
Rear Derailleur SHIMANO XT
Cassette SHIMANO XT 10-51
Chain SHIMANO XT
Chainring 34T
Crankset SHIMANO EM900 160MM
Brakes SRAM CODE RSC
Rotors SRAM CENTERLINE 220/SRAM CENTERLINE 200
Seatpost SRAM REVERB AXS 31.6MM SM: 125MM, MD: 150MM, LG/XL: 170MM
Handlebar YETI CARBON 35X800MM EBIKE
Stem RACE FACE TURBINE R 35X50MM
Grips ODI ELITE PRO
Saddle SILVERADO CUSTOM
Pedals N/A
Front Wheel DT SWISS EX1700 30MM Upgradable
Rear Wheel DT SWISS EX1700 30MM Upgradable
Front Tire MAXXIS ASSEGAI 2.5 EXO+
Rear Tire MAXXIS MINION DHR II 2.4 DD
Drive Unit
Battery SHIMANO 630Wh INTERNAL BATTERY
Display SHIMANO EM800
Extras Upgrades: DT Swiss EXC 1501 Carbon Wheelset
Sizes

"Every time I
find its limit,
I keep finding mine."

- Jared Graves, Multi-time World Champion and Olympian


WE DON’T PARTY UNTIL THE RACE IS OVER. SO WE TOOK OUR TIME TO DESIGN AN e-MTB THE WAY A YETI e-MTB HAS TO BE DESIGNED: READY TO TOE THE LINE AT EWS-E RACES. MEET THE 160E: THE WORLD’S FIRST RACE SPECIFIC e-MTB.

e-Bike Kinematics.

With the right suspension an e-MTB can do things a pedal bike can’t, taking you further, faster. Sixfinity delivers a suspension design that is expertly tuned for the added weight, speed and demands of an e-MTB.

EFFICIENCY AND TRACTION. OPTIMIZED.

Pedaling an e-MTB isn’t relegated to the low-end gear ranges. Across the entire cassette, there is a very small change in anti-squat (9%) in the pedal zone. Now, suspension performs consistently and predictably, regardless of gear choice. Bottom line: use the power efficiently in every single gear.

Fast. Beyond the Power.

The 25Km/h motor limit can be easily outpaced by racers. As a foundational design requirement, the 160E continues to elevate its performance and composure, the faster you go. So much so, Jared Graves has a new favorite bike.

Jared Graves EWS-E

Composed, planted, wickedly fast.

More trails. More laps. More of what you love. Sure, any e-MTB technically delivers “more”. More for the 160E is added composure, speed and agility. See also personal bests, wins, and championships.

Traction and Composure.
Achieved.

Due to the greater mass of an e-MTB, we reduced the anti-rise magnitude to 65%. Anti-rise remains consistent across the entire travel range, striking a balance for the unique demands of the added weight and power of an e-MTB.

Anti-Rise
%
65 At Sag
A lower magnitude than our traditional pedal bikes.
Tunable Leverage Rate.

Every track is different. Every racer has their ride preferences. Sixfinity has an adjustable leverage rate progression that provides a dynamic range of suspension feel. All while preserving geometry, anti-squat and anti-rise characteristics, and only a minute impact to wheel travel at +/-2mm.

Global Support.
For Global
Competition.

Working with our long-time race partner,
the Shimano EP8 motor and 630-watt hour
battery delivers consistent power to attack
any terrain. Best of all, the system has
hassle free, world-wide support.

Charge, While you Wrench.

The remote charging port and semi-integrated battery make race prep tuning easy while simultaneously charging the battery.

CHARGE TIME: 5 hours

BLUETOOTH ENABLED

Personalize the assist modes or integrate with your GPS, the 160E pairs with your smartphone using the Shimano E-tube apps.

Sleek Internal Wiring Management.

Integrated, internal wiring delivers a clean look for a zip tie free cockpit.

Guiding More than the Chain.

Factory race team sponsor, OneUp Components bridged the gap between our racing and engineering needs. Every 160E comes stock with a custom chain guide to prevent chain derailments and offer rattle-free cable management for mechanical drivetrains.

“HOW’D THEY DO THAT?”
SHORT CHAIN STAYS.

The answer is Sixfinity. Due to the incredibly compact packaging of the Infinity link, the 160E has shorter chain stays that eliminates the lazy-to-turn feel that plagues e-MTB's that utilize suspension designs carried forward from pedal only designs. Without resorting to smaller wheel sizes and leaving traction and speed on the table, our 29” wheel chainstays are shorter than other brands compensating mullet setups.

A Slightly Higher BB.
Say What?

At 350mm, the 160E’s bottom bracket height is a bit higher than our SB150 pedal bike. The slightly higher BB paired with shorter cranks means racers realize the gains of extra pedal strokes.

INFINITE SUSPENSION CAPABILITY, REALIZED FOR THE DEMANDS OF e-MTB. MEET SIXFINITY. Explore160E Geo Chart



    SM MD LG XL
A SEAT TUBE LENGTH 15 16.1 17.7 19.5
B TOPTUBE LENGTH 22.1 23.3 24.1 25.3
C HEADTUBE ANGLE 64.5 64.5 64.5 64.5
D EFF. SEAT TUBE ANGLE 78
E CHAINSTAY LENGTH 17.6
F WHEELBASE 47.6 48.8 49.7 50.9
G ESTIMATED BB HEIGHT 13.8
H STANDOVER 29.7 29.7 29.7 29.7
I HEADTUBE LENGTH 3.7 3.9 4.1 4.5
J AXLE TO CROWN 23
K OFFSET 1.7
L STACK 24.3 24.4 24.6 25
M REACH 16.9 18.1 18.9 19.9
N FRONT CENTER 30 31.2 32.1 33.3

measured in inches
