700c | 63mm Front Travel | 70° HT
| Size / mm | S | M | L | XL | |
| 1 | ST Length | 381 | 432 | 483 | 533 |
| 2 | TT Length | 572 | 597 | 623 | 647 |
| 3 | Reach | 398 | 419 | 439 | 458 |
| 4 | Stack | 590 | 603 | 622 | 641 |
| 5 | Standover | 691 | 734 | 773 | 812 |
| 6 | HT Angle | 70 | 70 | 70 | 70 |
| 7 | HT Length | 110 | 130 | 150 | 170 |
| 8 | ST Angle | 73.5 | 73.5 | 73.5 | 73.5 |
| 9 | CS Length | 440 | 440 | 440 | 440 |
| 10 | BB Drop | 58 | 53 | 53 | 53 |
| 11 | BB Height | 297 | 302 | 302 | 302 |
| 12 | Wheelbase | 1072 | 1100 | 1127 | 1153 |
| 13 | Front Center | 638 | 666 | 692 | 718 |
| 14 | Fork Length | 467 | 467 | 467 | 467 |
| 15 | Fork Offset | 42 | 42 | 42 | 42 |
| Frame Material | Kona 6061 Aluminum Butted |
|---|---|
| Sizes | S, M, L, XL |
| Fork | Suntour NEX Coil Spring 63mm |
| Crankarms | Shimano Altus |
| Chainrings | 22/32/42t |
| Bottom Bracket | CH52 |
| Pedals | Kona JS2 |
| Chain | KMC Z51 |
| Cassette | Shimano Altus 11-34t 8spd |
| Chainguide | N/A |
| Front Derailleur | Shimano Tourney |
| Rear Derailleur | Shimano Tourney |
| Shifters | Shimano Altus |
| Brake Calipers | Tektro HDM275 |
| Front Brake Rotor | Tektro TR160 160mm |
| Rear Brake Rotor | Tektro TR160 160mm |
| Brake Levers | Tektro HDM275 |
| Headset | FSA No.10P |
| Handlebar | Kona Aluminum Riser |
| Stem | Kona Control |
| Seatpost | Kona Thumb w/Offset 27.2mm |
| Seatpost Clamp | Kona Clamp |
| Grips | Kona Key Grip Slip on |
| Saddle | Kona Crosstrail |
| Front Hub | Formula 100x9mm |
| Rear Hub | Formula 135x10mm |
| Spokes | Stainless Black 14g |
| Rims | Double Wall alloy |
| Front Tire | Vee Tire Rail 700x40c |
| Rear Tire | Vee Tire Rail 700x40c |
| Paint Color | Gloss Dark Seafoam |
